The MPLAB® Snap In-Circuit Debugger/Programmer allows affordable, fast and easy debugging and programming of most PIC®, dsPIC® and AVR flash MCUs, using the powerful graphical user interface of MPLAB X Integrated Development Environment (IDE) version 5.05 or later. The MPLAB Snap can be connected to a computer using a High-Speed USB 2.0 interface and can be connected to the target via an 8-pin Single In-Line (SIL) connector. The connector uses two device I/O pins and the reset line to implement in-circuit debugging and In-Circuit Serial Programming™ (ICSP™). It has all the speed and features entry-level users need to quickly debug their prototype.
The MPLAB Snap programs fast, with a powerful 32-bit 300MHz SAME70 MCU for quicker debug iterations. Along with a wide target voltage, the MPLAB Snap supports advanced interfaces such as 4-wire JTAG and Serial Wire Debug with streaming data gateway, while being backward compatible for demo boards, headers and target systems using 2-wire JTAG and ICSP.
Note: The Snap is compatible with MPLAB X IDE version 5.05 and later.
• MPLAB Snap In-Circuit Debugger/Programmer
- Affordable performance, only $14.95
- Matches silicon clocking speed
- Programs as fast as the device will allow
- Target voltage of 1.20V to 5.5V
- Wide target voltage supports a variety of devices
- Powered by a high-speed USB 2.0, no external power
required
- 8-pin single in-line header
- Supports advanced interfaces such as 4-wire JTAG and
Serial Wire Debug with streaming data gateway
- Backward compatible for demo boards, headers and target
systems using 2-wire JTAG and ICSP
- Ease of maintenance and feature upgrade
